Features |
|
• 24 cores or 48 cores |
|
• Steel material |
|
• Indoor on the wall |
|
• Easy to exchange adapter plate |
|
• Suitable for SC,LC,ST,FC,E2000 adapter,48 ports |
|
• Hold up to 96 fiber,with LC Duplex adapter |
|
• Accepts distribution , breakout cables |
|
• Double door |
|
• 5pcs cable entries,Entry location is optional |
|
• IP50 |
|
Application |
|
• Data center,premise installations and telecommunication networks |
|
• Ethernet,fibre channel,ATM,LAN,MAN and WAN |
|
• Data communication |
|
• FTTH |
|
Prat No. |
Outline Dimension (LxWxH) |
Core Max& Type |
Input Diameter |
|
MAX0310-24C |
385x400x100mm |
24Core SC/LC/ST/FC adapter |
50mm x 1pc , 20mm x 4pcs |
|
MAX0310-48C |
385x400x100mm |
48Core SC/LC/ST/FC adapter |
50mm x 1pc , 20mm x 4pcs |
|
MAX0310-96C |
385x400x100mm |
96Core LC Duplex adapter |
50mm x 1pc , 20mm x 4pcs |
