Type |
Singlemode(UPC) |
Singlemode(APC) |
Multi-mode(UPC) |
|
Insertion Loss (dB) |
≤0.20 |
≤0.20 |
≤0.20 |
|
Return Loss (dB) |
≥55 |
≥60 |
≥35 |
|
Repeatability Loss(dB) |
|
≤0.10 |
|
|
Repeat Piug-pull Times |
|
≥1000 |
|
|
Tensil Strength(N) |
|
≥100 |
|
|
Operating Temperature(℃) |
|
-40℃~+75℃ |
|
|
Storage Temperature(℃) |
|
-40℃~+85℃ |
|
|
Part No. |
Connector |
Pigtail/Jumper |
Fiber Count |
Fiber Type |
Cable Diameter |
Jack Type |
Length |
|
MAX0404 |
SC/UPC |
Pigtail |
Simplex |
SM-G652 |
09:0.9mm |
LSZH |
1meter |
|
|
SC/APC |
Jumper |
Duplex |
SM-G655 |
20:2.0mm |
PVC |
2meter |
|
|
|
|
|
SM-G657A1 |
30:3.0mm |
|
3meter |
|
|
|
|
|
SM-G657A2 |
24:2.4mm |
|
5meter |
|
|
|
|
|
OM1 |
|
|
10meter |
|
|
|
|
|
OM2 |
|
|
15meter |
|
|
|
|
|
OM13 |
|
|
20meter |
|
|
|
|
|
|
|
|
30meter |
|
|
|
|
|
|
|
|
100meter |
