| Name | FTTH Wall mounting terminal box | ||||
| Part No. | MAX0115-V3 | ||||
| Outline Dimension (LxWxH) | 303x101x48mm | ||||
| Port Type | 2ports SC Simplex adapter | ||||
| 2ports LC Duplex adapter | |||||
| Installation | Wall Mount (Indoor) | ||||
| Color | White | ||||
| Material | ABS | ||||
|
Features |
|||||
| •Easy connection and splice | |||||
| •With 15pcs clips can remove , easy to input or output cable | |||||
| •Expediently installation |
| Part No. | Description | ||||
| MAX0110-V3 | FTTH wall box without adapter and pigtail | ||||
| MAX0110-V3-2SC | FTTH wall box with 2pcs SC adapter,without pigtail | ||||
| MAX0110-V3-2SC-P | FTTH wall box with 2pcs SC adapter,with 2pcs pigtail | ||||
| MAX0110-V3-2LC | FTTH wall box with 2pcs LC duplex adapter,without pigtail | ||||
| MAX0110-V3-2LC-P | FTTH wall box with 2pcs LC duplex adapter,with 4pcs pigtail | ||||
