Product Advantages
·Detection range up to <2.5m.
·High location precision marker ball.
·No harmful chemical substances inside.
·For manholes or direct buried installation.
·Self orientation RF reflector ensures best detection range and accuracy.
·Designed according to international standard frequencies.
| Product Specifications | |
| Construction | Description |
| Product Type | EX.ID version |
| Frequency | 169.8 kHz / 145.7 kHz / 121.6 kHz / 101.4 kHz / 134 kHz / 83 kHz / 66.35 kHz |
| Maximum Detectable Depth | 2.25~2.5 m (EX.ID version) |
| Service Life | 50 years |
| Diameter | Φ215mm丨8.46in |
| Height | 30mm丨1.18in |
| Material | HDPE or ABS packaging, resistant to chemical corrosion |
| Weight | 0.217 kg ± 10% |
| Protection Level | IP68 |
| Storage Temperature | -30℃ to +55℃ |
| Operating Temperature | -30℃ to +55℃ |
| Installing Density | Usually 10~20m |
| Anti-drop Ability | Able to withstand drops from a height of 3 meters without affecting electrical performance |
| Pressure Resistance | Able to withstand pressure of 20KN without being damaged |
| Detector Compatibility | ED8000 or other detectors with the same frequency (for example: 3M Dynatel series) can read |
