Product Advantages
·Maximum local cache of 250 records. (repeated overwrite storage)
·Upgrade clip interface for convenient device and mobile app interchange.
·Vertical detachable base allows for easy detection even when the device is removed.
·Built-in GPS positioning chip for longitude and latitude information from detection signals.
·Supports 7 operating frequencies. (66.35 kHz, 77.0 kHz, 83.0 kHz, 101.4 kHz, 121.6 kHz, 145
.7 kHz, 169.8 kHz)
| Product Specifications | |
| Construction | Description |
| Material | ABS |
| Recognizable Frequency | 66.35 kHz, 77.0 kHz, 83.0 kHz, 101.4 kHz, 121.6 kHz, 145.7 kHz, 169.8 kHz |
| Height | 750.00mm | 29.530in |
| Width | 270.00mm | 10.630in |
| Length | 120.00mm | 4.720in |
| Weight | 2.45kg±5%(Conventional antenna without base) 2.85kg±5%(Regular antenna with base) 3.10kg±5%(Extended antenna with base) |
| Waterproof Grade | IP54 |
| Max. Detection Distance | 2.8m(varies depending on frequency) |
| Max. ID Read Distance | 3.0m(varies depending on frequency) |
| Max. Date Write Distance | 0.8m(varies depending on frequency) |
| Antenna Gain | 14DBi~16DBi |
| Alert Tone | Alarm or Ring Tone |
